TF03-100/180
180mIP67LiDAR
Light
Weight
Compact
Design
High
Accuracy
Long
Range
Low Power Consumption

TF03 IP67 Long Range LiDAR Sensor


The TF03, as the third generation product of the TF series, inherits the high cost-effectiveness and high integration characteristics of the previous two generations while upgrading more than ten key indicators. It offers multiple extended functions and boasts high product maturity, meeting the diverse needs of different application fields. It is primarily used in areas such as drones, intelligent transportation, and security warning systems.


01
Compact, yet so powerful


The TF03 features a unique optical system and signal processing circuit design, which enhances ranging performance while maintaining a compact size. In addition to a range exceeding one hundred meters, key parameters such as accuracy and detection frame rate also perform excellently across the entire range. There is also a custom version without an outer shell that is lighter (10g) and smaller (31.0*30.2*19.2mm). For detailed specifications, please consult Benewake customer service.

180m
Operating range
Min 0.1m
Blind area
Max 7KHz
Frame rate
100Klux
Ambient light immunity
02
High Enclosure Rate, Multiple Interfaces


TF03 LiDAR
has a shell made of aluminum alloy and infrared band-pass glass to improve the overall strength and long-term reliability in various conditions. For functionality, multiple interfaces like UART, CAN, RS232, and RS485 are integrated into this long-distance LiDAR to enable robust real-time data exchange, crucial for accuracy and safety in vehicle collision avoidance, assisted takeoff, and landing of UAV and traffic flow analysis.

03
Customized Operation Mode


According to the usage scenario, users can customize multiple parameters of the TF03, such as output frame rate, baud rate, trigger mode, and over-range threshold. It also features a built-in BootLoader function, allowing users to conveniently upgrade the product firmware locally. Additionally, there are customized products specifically designed for drone applications; users can consult Benewake customer service for detailed parameters.

Industrial applications
Industrial applications
