Short Distance Series Product Model
TF-NOVA
TF-NOVA
Learn More Add to Comparison
Dimensions (L*W*H)26.5 mm × 21.05 mm × 12 mm
InterfaceUART, I/O, I²C
Protection LevelN/A
Range14 m
Frame Rate1 ~ 900 Hz
Power ConsumptionTBD
Weight< 5 g
TF-Luna
TF-Luna
Learn More Add to Comparison
Dimensions (L*W*H)35 mm × 21.25 mm × 13.5 mm
InterfaceUART, I/O, I²C
Protection LevelN/A
Range0.2 ~ 8 m
Frame Rate1 ~ 250 Hz
Power Consumption≤ 0.35 W
Weight< 5 g
TFmini-S
TFmini-S
Learn More Add to Comparison
Dimensions (L*W*H)42 mm × 15 mm × 16 mm
InterfaceUART, I/O, I²C
Protection LevelN/A
Range0.1 ~ 12 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 0.7 W
Weight5 ± 0.3 g
TFmini Plus
TFmini Plus
Learn More Add to Comparison
Dimensions (L*W*H)35 mm × 18.5 mm × 21 mm
InterfaceUART, I/O, I²C
Protection LevelIP65
Range0.1 ~ 12 m
Frame Rate1 ~ 1000 Hz
Power Consumption550 mW
Weight12 ± 1 g
TFmini-i
TFmini-i
Learn More Add to Comparison
Dimensions (L*W*H)50 mm × 34 mm × 41 mm
InterfaceCAN, RS-485
Protection LevelIP65
Range0.1 ~ 12 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 0.8 W @ 12 V
Weight52 g
TFS20-L
TFS20-L
Learn More Add to Comparison
Dimensions (L*W*H)21 mm × 15 mm × 7.87 mm
InterfaceUART, I²C
Protection LevelN/A
Range0.2 ~ 20 m
Frame Rate1 ~ 250 Hz
Power Consumption≤ 0.35 W
Weight~ 1.35 g
Medium Distance Series Product Model
TF02-Pro
TF02-Pro
Learn More Add to Comparison
Dimensions (L*W*H)69 mm × 41.5 mm × 26 mm
InterfaceUART, I/O, I²C
Protection LevelIP65
Range0.1 ~ 40 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 1 W
Weight50 g
TF02-i
TF02-i
Learn More Add to Comparison
Dimensions (L*W*H)69 mm × 40.5 mm × 31.25 mm
InterfaceCAN, RS-485
Protection LevelIP65
Range0.1 ~ 40 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 0.85 W @ 12 V
Weight60 g
TF02-Pro-W
TF02-Pro-W
Learn More Add to Comparison
Dimensions (L*W*H)85 mm × 59 mm × 43 mm
InterfaceUART, RS-485, I/O, I²C
Protection LevelIP5X
Range0.1 ~ 25 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 2 W
Weight90 ~ 92 g
Long Distance Series Product Model
TF03
TF03
Learn More Add to Comparison
Dimensions (L*W*H)44 mm × 43 mm × 32 mm
InterfaceUART, CAN, RS-232, RS-485, 4 - 20mA
Protection LevelIP67
Range0.1 ~ 180 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 1 W
Weight89 ± 3 g
TFA300 Series
TFA300 Series
Learn More Add to Comparison
Dimensions (L*W*H)32.0 mm × 30.2 mm × 20.2 mm
InterfaceUART, CAN
Protection LevelN/A
Range0.1 ~ 290 m
Frame Rate1 ~ 10,000 Hz
Power Consumption≤ 0.45 W
Weight10.5 g
TF350
TF350
Learn More Add to Comparison
Dimensions (L*W*H)78 mm × 67 mm × 40 mm
InterfaceUART, CAN, RS-232, RS-485, 4 - 20mA
Protection LevelIP67
Range0.2 ~ 350 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 1 W
Weight224 ± 3 g
Kilometer-level
TFA1200-L
TFA1200-L
Learn More Add to Comparison
Dimensions (L*W*H)25 mm × 25 × 13 mm
InterfaceUART
Protection LevelN/A
Range3 ~ 1200 m
Frame Rate3 Hz
Power Consumption< 1.1 W
Weight11 g
TFA1500-L
TFA1500-L
Learn More Add to Comparison
Dimensions (L*W*H)33 mm × 34 mm × 18 mm
InterfaceUART
Protection LevelN/A
Range0.05 ~ 1500 m
Frame Rate50 Hz @ long range
1000 Hz @ close range
Power Consumption< 1.1 W
Weight20 g
2D Series..

TR Series
TR Serise
TR Serise
Learn More Add to Comparison
Dimensions (L*W*H)60 mm × 60 mm × 80 mm
Interface
Protection LevelIP65
Range40 m
Frame Rate10 ~ 30 Hz
Power Consumption
Weight
3D Series..

Long Distance Series Product Model
AD2-S-X3
AD2-S-X3
Learn More Add to Comparison
Dimensions (L*W*H)49 mm × 160 mm × 144 mm
Interface1000Base-T1 Automotive Ethernet
Protection LevelIP67 & IP6K9K
Range200 m @ 10%
Frame Rate10 Hz
Power Consumption≤ 15 W
Weight1.2 kg
Horn-X2 Pro
Horn-X2 Pro
Learn More Add to Comparison
Dimensions (L*W*H)192.6 mm × 157 mm × 126 mm
Interface1000Base-T
Protection LevelIP67
Range300 m @ 10%
Frame Rate1 ~ 20 FPS
Power Consumption≤ 35 W
Weight≤ 3.8 kg
Horn-RT
Horn-RT
Learn More Add to Comparison
Dimensions (L*W*H)183 mm × 157 mm × 120 mm
Interface1000Base-T
Protection LevelIP67
Range300 m @ 10%
Frame Rate1 ~ 20 FPS
Power Consumption≤ 35 W
Weight≤ 3.3 kg
Applications
Autonomous Mobility
ADAS Unmanned Mining Trucks Smart Logistics - Last-Mile Unmanned Delivery Autonomous Driving Truck Operation
UAV
Terrain Following Position Hold
Level Detection
Level Detection Volume Detection Liquid level measurement Space & People Flow Detection
Robot
Pallet Transport Robot Obstacle Avoidance Crane Positioning / Obstacle Avoidance Robot Fall Prevention & Obstacle Avoidance
Smart Transportation
Vehicle Door Obstacle Avoidance Smart Parking Automotive Electric Tailgate Highway Key Area Monitoring V2X / Holographic Intersection / Traffic Light Control Meli train collision avoidance system Smart Civil Aviation
IoT
Auxiliary Focus Smart Trigger Security Warning Rotary door anti-clamping
Download
About Us
Distributors News Contact Us
中EN
Contact
UAV


Terrain Following
Laser rangefinder provides highly reliable absolute distance data with centimeter-level accuracy
Position Holding//Hovering
Laser rangefinder with a divergence angle of less than 0.5°, can accurately target fine structures smaller than 10 cm at distances beyond 10 meters
Gimbal Rangefinding
Gimbal integrated LiDAR for intelligent focused tracking and relative object positioning
Stable-altitude Cruising
Maintain centimeter-level stability while cruising and hovering at altitudes above 200 meters
Detect and Avoid
Ensure safety by detecting obstacles in real time and assists flight controllers in taking evasive measures
Your Drone Pain Points, Solved
As Light as 5g Extended Operation Endurance
Miniaturization Increased Payload Capacity
Integrated Rain-Fog Algorithm Strong Environmental Adaptability
Long Range Remote Assisted Focus
Million Units Shipped Mass Production Quality Assurance
DO-160G Certification Reliability & Safety
How Benewake Addresses the Pain Points
Light weight to 5g
Compact design
More compact with high integration
Market-proven product
DO-160G
Capable of passing DO-160G certification, allowing it to withstand various harsh airborne environments
Core Functions
01
Terrain following/holding
Provide highly reliable absolute distance data with centimeter-level accuracy
02
Position hold
With a divergence angle of less than 0.5°, can accurately target fine structures smaller than 10 cm at distances beyond 10 meters
03
Autonomous takeoff and landing
Can perfectly meet the high-precision measurement requirements for autonomous takeoff and landing in the critical distance range
04
Depth perception and pinpoint
Can provide real-time measurements of target objects as small as 1.5 meters from 170 meters away
Customers Case
Drone with Pod/Gimbal
Logistic Drone
Product Recommendations
TF-Luna
0.2 ~ 8 m
1 ~ 250 Hz
≤ 0.35 W
< 5 g
UART,I/O,I²C
TF02-Pro
0.1 ~ 40 m
1 ~ 1000 Hz
≤ 1 W
50 g
UART,I/O,I²C
