Single-point..
Short Distance Series Product Model
TF-NOVA
TF-NOVA
Learn More
Add to Comparison
Dimensions (L*W*H)
26.5 mm × 21.05 mm × 12 mm
Interface
UART, I/O, I²C
Protection Level
N/A
Range
14 m
Frame Rate
1 ~ 900 Hz
Power Consumption
TBD
Weight
< 5 g
TFS20-L
TFS20-L
Learn More
Add to Comparison
Dimensions (L*W*H)
21 mm × 15 mm × 7.87 mm
Interface
UART, I²C
Protection Level
N/A
Range
0.2 ~ 20 m
Frame Rate
1 ~ 250 Hz
Power Consumption
≤ 0.35 W
Weight
~ 1.35 g
TF-Luna
TF-Luna
Learn More
Add to Comparison
Dimensions (L*W*H)
35 mm × 21.25 mm × 13.5 mm
Interface
UART, I/O, I²C
Protection Level
N/A
Range
0.2 ~ 8 m
Frame Rate
1 ~ 250 Hz
Power Consumption
≤ 0.35 W
Weight
< 5 g
TFmini-S
TFmini-S
Learn More
Add to Comparison
Dimensions (L*W*H)
42 mm × 15 mm × 16 mm
Interface
UART, I/O, I²C
Protection Level
N/A
Range
0.1 ~ 12 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 0.7 W
Weight
5 ± 0.3 g
TFmini Plus
TFmini Plus
Learn More
Add to Comparison
Dimensions (L*W*H)
35 mm × 18.5 mm × 21 mm
Interface
UART, I/O, I²C
Protection Level
IP65
Range
0.1 ~ 12 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
550 mW
Weight
12 ± 1 g
TFmini-i
TFmini-i
Learn More
Add to Comparison
Dimensions (L*W*H)
50 mm × 34 mm × 41 mm
Interface
CAN, RS-485
Protection Level
IP65
Range
0.1 ~ 12 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 0.8 W @ 12 V
Weight
52 g
Medium Distance Series Product Model
TF02-Pro
TF02-Pro
Learn More
Add to Comparison
Dimensions (L*W*H)
69 mm × 41.5 mm × 26 mm
Interface
UART, I/O, I²C
Protection Level
IP65
Range
0.1 ~ 40 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 1 W
Weight
50 g
TF02-i
TF02-i
Learn More
Add to Comparison
Dimensions (L*W*H)
69 mm × 40.5 mm × 31.25 mm
Interface
CAN, RS-485
Protection Level
IP65
Range
0.1 ~ 40 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 0.85 W @ 12 V
Weight
60 g
TF02-Pro-W
TF02-Pro-W
Learn More
Add to Comparison
Dimensions (L*W*H)
85 mm × 59 mm × 43 mm
Interface
UART, RS-485, I/O, I²C
Protection Level
IP5X
Range
0.1 ~ 25 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 2 W
Weight
90 ~ 92 g
Long Distance Series Product Model
TFA170-L
TFA170-L
Learn More
Add to Comparison
Dimensions (L*W*H)
31.0 mm × 30.2 mm × 19.2 mm
Interface
RS-232
Protection Level
N/A
Range
0.1 ~ 170 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 1 W
Weight
~ 10 g
TF03
TF03
Learn More
Add to Comparison
Dimensions (L*W*H)
44 mm × 43 mm × 32 mm
Interface
CAN, 4-20mA, RS-232, RS-485, UART
Protection Level
IP67
Range
0.1 ~ 180 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 1 W
Weight
89 ± 3 g
TF350
TF350
Learn More
Add to Comparison
Dimensions (L*W*H)
78 mm × 67 mm × 40 mm
Interface
CAN, 4-20mA, RS-232, RS-485, UART
Protection Level
IP67
Range
0.2 ~ 350 m
Frame Rate
1 ~ 1000 Hz
Power Consumption
≤ 1 W
Weight
224 ± 3 g
Kilometer-level
TFA1200-L
TFA1200-L
Learn More
Add to Comparison
Dimensions (L*W*H)
25 mm × 25 × 13 mm
Interface
UART
Protection Level
N/A
Range
3 ~ 1200 m
Frame Rate
3 Hz
Power Consumption
< 1.1 W
Weight
11 g
TFA1500-L
TFA1500-L
Learn More
Add to Comparison
Dimensions (L*W*H)
33 mm × 34 mm × 18 mm
Interface
UART
Protection Level
N/A
Range
0.05 ~ 1500 m
Frame Rate
50 Hz @ long range
1000 Hz @ close range
Power Consumption
< 1.1 W
Weight
20 g
2D Series..
TR Series
TR Serise
TR Serise
Learn More
Add to Comparison
Dimensions (L*W*H)
60 mm × 60 mm × 80 mm
Interface
Protection Level
IP65
Range
40 m
Frame Rate
10 ~ 30 Hz
Power Consumption
Weight
3D Series..
Long Distance Series Product Model
AD2-S-X3
AD2-S-X3
Learn More
Add to Comparison
Dimensions (L*W*H)
49 mm × 160 mm × 144 mm
Interface
1000Base-T1 Automotive Ethernet
Protection Level
IP67 & IP6K9K
Range
200 m @ 10%
Frame Rate
10 Hz
Power Consumption
≤ 15 W
Weight
1.2 kg
Horn-X2 Pro
Horn-X2 Pro
Learn More
Add to Comparison
Dimensions (L*W*H)
192.6 mm × 157 mm × 126 mm
Interface
1000Base-T
Protection Level
IP67
Range
300 m @ 10%
Frame Rate
1 ~ 20 FPS
Power Consumption
≤ 35 W
Weight
≤ 3.8 kg
Horn-RT
Horn-RT
Learn More
Add to Comparison
Dimensions (L*W*H)
183 mm × 157 mm × 120 mm
Interface
1000Base-T
Protection Level
IP67
Range
300 m @ 10%
Frame Rate
1 ~ 20 FPS
Power Consumption
≤ 35 W
Weight
≤ 3.3 kg
