NOVA20 Solid state multi-point lidar

Short Distance Series Product Model

Learn More Add to Comparison

Dimensions (L*W*H)24mm×16mm ×20.4mm

InterfaceUART, I²C

Protection Levelwithout enclosure

Power Consumption＜ 5V × 100mA

Learn More Add to Comparison

Dimensions (L*W*H)26.5 mm × 21.05 mm × 12 mm

InterfaceUART, I/O, I²C

Protection Levelwithout enclosure

Frame Rate1 ~ 900 Hz

Power ConsumptionTBD

Learn More Add to Comparison

Dimensions (L*W*H)35 mm × 21.25 mm × 13.5 mm

InterfaceUART, I/O, I²C

Protection Levelwithout enclosure

Frame Rate1 ~ 250 Hz

Power Consumption≤ 0.35 W

Learn More Add to Comparison

Dimensions (L*W*H)42 mm × 15 mm × 16 mm

InterfaceUART, I/O, I²C

Protection LevelIP65

Range0.1 ~ 12 m

Frame Rate1 ~ 1000 Hz

Power Consumption≤ 0.7 W

Weight5 ± 0.3 g

Learn More Add to Comparison

Dimensions (L*W*H)35 mm × 18.5 mm × 21 mm

InterfaceUART, I/O, I²C

Protection LevelIP65

Range0.1 ~ 12 m

Frame Rate1 ~ 1000 Hz

Power Consumption550 mW

Weight12 ± 1 g

Learn More Add to Comparison

Dimensions (L*W*H)50 mm × 34 mm × 41 mm

InterfaceCAN, RS-485

Protection LevelIP65

Range0.1 ~ 12 m

Frame Rate1 ~ 1000 Hz

Power Consumption≤ 0.8 W @ 12 V

Learn More Add to Comparison

Dimensions (L*W*H)21 mm × 15 mm × 7.87 mm

InterfaceUART, I²C

Protection Levelwithout enclosure

Range0.2 ~ 20 m

Frame Rate1 ~ 250 Hz

Power Consumption≤ 0.35 W

Medium Distance Series Product Model

Learn More Add to Comparison

Dimensions (L*W*H)69 mm × 41.5 mm × 26 mm

InterfaceUART, I/O, I²C

Protection LevelIP65

Range0.1 ~ 40 m

Frame Rate1 ~ 1000 Hz

Power Consumption≤ 1 W

Learn More Add to Comparison

Dimensions (L*W*H)69 mm × 40.5 mm × 31.25 mm

InterfaceCAN, RS-485

Protection LevelIP65

Range0.1 ~ 40 m

Frame Rate1 ~ 1000 Hz

Power Consumption≤ 0.85 W @ 12 V

Learn More Add to Comparison

Dimensions (L*W*H)85 mm × 59 mm × 43 mm

InterfaceUART, RS-485, I/O, I²C

Protection LevelIP5X

Range0.1 ~ 25 m

Frame Rate1 ~ 1000 Hz

Power Consumption≤ 2 W

Weight90 ~ 92 g

Long Distance Series Product Model

Learn More Add to Comparison

Dimensions (L*W*H)31.0 mm × 30.2 mm × 19.2 mm

InterfaceRS-232

Protection Levelwithout enclosure

Range0.1 ~ 170 m

Frame Rate1 ~ 1000 Hz

Power Consumption≤ 1 W

Learn More Add to Comparison

Dimensions (L*W*H)44 mm × 43 mm × 32 mm

InterfaceUART, CAN, RS-232, RS-485

Protection LevelIP67

Range0.1 ~ 180 m

Frame Rate1 ~ 9800 Hz

Power Consumption≤ 1 W

Weight86 ± 3 g

Learn More Add to Comparison

Dimensions (L*W*H)49.4 mm × 37.0 mm × 28.6 mm

InterfaceUART, CAN

Protection LevelIP67

Range0.1 ~ 290 m

Frame Rate1 ~ 10,000 Hz

Power Consumption≤ 0.45 W

Learn More Add to Comparison

Dimensions (L*W*H)78 mm × 67 mm × 40 mm

InterfaceUART, CAN, RS-232, RS-485

Protection LevelIP67

Range0.2 ~ 350 m

Frame Rate1 ~ 1000 Hz

Power Consumption≤ 1 W

Weight224 ± 3 g

Kilometer-level

Learn More Add to Comparison

Dimensions (L*W*H)25 mm × 25 × 13 mm

Protection Levelwithout enclosure

Range3 ~ 1200 m

Power Consumption< 1.1 W

Learn More Add to Comparison

Dimensions (L*W*H)≤ 25 mm × 26 mm × 13 mm

Protection Levelwithout enclosure

Range0.5 ~ 1500 m

Frame Rate60 ~ 800Hz (adaptive)

Power Consumption≤ 1.8W

NOVA20

Learn More Add to Comparison

Dimensions (L*W*H)≤25 * 22 * 14mm

Protection Level

Range1m@10 %Reflectivity, 100Klux

Power Consumption< 1W

VLS Series

Learn More Add to Comparison

Dimensions (L*W*H)52.0 mm × 75.0 mm × 53.1 mm

Protection LevelIPX8

Power Consumption

TR Series

Learn More Add to Comparison

Dimensions (L*W*H)60 mm × 60 mm × 80 mm

Protection LevelIP65

Frame Rate10 ~ 30 Hz

Power Consumption

Long Distance Series Product Model

Learn More Add to Comparison

Dimensions (L*W*H)92 mm × 47 mm × 51 mm

InterfaceEthernet, GMSL, I/O

Protection LevelIP67

Frame Rate10fps

Power Consumption

Learn More Add to Comparison

Dimensions (L*W*H)49 mm × 160 mm × 144 mm

Interface1000Base-T1 Automotive Ethernet

Protection LevelIP67 & IP6K9K

Range300 m @ 10%

Frame Rate10 Hz

Power Consumption≤ 15 W

Learn More Add to Comparison

Dimensions (L*W*H)192.6 mm × 157 mm × 126 mm

Interface1000Base-T

Protection LevelIP67

Range300 m @ 10%

Frame Rate1 ~ 20 FPS

Power Consumption≤ 35 W

Weight≤ 3.8 kg

Learn More Add to Comparison

Dimensions (L*W*H)183 mm × 157 mm × 120 mm

Interface1000Base-T

Protection LevelIP67

Range300 m @ 10%

Frame Rate1 ~ 20 FPS

Power Consumption≤ 35 W

Weight≤ 3.3 kg

Distributors News Contact Us

bw@benewake.com

NOVA20 Solid state multi-point lidar

NOVA20 is a short-range, lightweight, multi-beam LiDAR that covers a 40° field of view and enables simultaneous detection across 20 channels. With centimeter-level accuracy and reliable ranging performance both indoors and outdoors, NOVA20 is ideal for blind-spot detection and drop-off prevention in outdoor robots, unmanned vehicles, and similar applications.

01

More exquisite design, richer information

NOVA20 inherits the NOVA series’ line-spot technology, providing a wider field of view and richer ranging data than single-point detection for enhanced spatial awareness.

1m 1 m @ 10% reflectivity

Measurement range

10 Hz

Frame rate

< 1 W

Average power consumption

< 5 g

Weight

02

Reliable detection, adaptable to multiple scenarios

With a blind zone of less than 5 cm and centimeter-level accuracy, NOVA20 is suitable for spatial detection, switch triggering, and other applications, delivering rich data and precise detection.

High ambient-light resistance

Light weight

Wonderful Vibration resistant

03

Not afraid of the scorching sun, not afraid of darkness

Even under outdoor ambient light of 100 klux, NOVA20 delivers reliable detection at 1 m, making it ideal for blind-spot detection, traversability assessment, and other applications involving robot chassis and unmanned vehicles.
