Short Distance Series Product Model
TF-UW500
TF-UW500
Learn More Add to Comparison
Dimensions (L*W*H)24mm×16mm ×20.4mm
InterfaceUART, I²C
Protection Levelwithout enclosure
Range＞ 5 m
Frame Rate20Hz
Power Consumption＜ 5V × 100mA
Weight＜ 5 g
TF-NOVA
TF-NOVA
Learn More Add to Comparison
Dimensions (L*W*H)26.5 mm × 21.05 mm × 12 mm
InterfaceUART, I/O, I²C
Protection Levelwithout enclosure
Range14 m
Frame Rate1 ~ 900 Hz
Power ConsumptionTBD
Weight< 5 g
TF-Luna
TF-Luna
Learn More Add to Comparison
Dimensions (L*W*H)35 mm × 21.25 mm × 13.5 mm
InterfaceUART, I/O, I²C
Protection Levelwithout enclosure
Range0.2 ~ 8 m
Frame Rate1 ~ 250 Hz
Power Consumption≤ 0.35 W
Weight< 5 g
TFmini-S
TFmini-S
Learn More Add to Comparison
Dimensions (L*W*H)42 mm × 15 mm × 16 mm
InterfaceUART, I/O, I²C
Protection LevelIP65
Range0.1 ~ 12 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 0.7 W
Weight5 ± 0.3 g
TFmini Plus
TFmini Plus
Learn More Add to Comparison
Dimensions (L*W*H)35 mm × 18.5 mm × 21 mm
InterfaceUART, I/O, I²C
Protection LevelIP65
Range0.1 ~ 12 m
Frame Rate1 ~ 1000 Hz
Power Consumption550 mW
Weight12 ± 1 g
TFmini-i
TFmini-i
Learn More Add to Comparison
Dimensions (L*W*H)50 mm × 34 mm × 41 mm
InterfaceCAN, RS-485
Protection LevelIP65
Range0.1 ~ 12 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 0.8 W @ 12 V
Weight52 g
TFS20-L
TFS20-L
Learn More Add to Comparison
Dimensions (L*W*H)21 mm × 15 mm × 7.87 mm
InterfaceUART, I²C
Protection Levelwithout enclosure
Range0.2 ~ 20 m
Frame Rate1 ~ 250 Hz
Power Consumption≤ 0.35 W
Weight~ 1.35 g
Medium Distance Series Product Model
TF02-Pro
TF02-Pro
Learn More Add to Comparison
Dimensions (L*W*H)69 mm × 41.5 mm × 26 mm
InterfaceUART, I/O, I²C
Protection LevelIP65
Range0.1 ~ 40 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 1 W
Weight50 g
TF02-i
TF02-i
Learn More Add to Comparison
Dimensions (L*W*H)69 mm × 40.5 mm × 31.25 mm
InterfaceCAN, RS-485
Protection LevelIP65
Range0.1 ~ 40 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 0.85 W @ 12 V
Weight60 g
TF02-Pro-W
TF02-Pro-W
Learn More Add to Comparison
Dimensions (L*W*H)85 mm × 59 mm × 43 mm
InterfaceUART, RS-485, I/O, I²C
Protection LevelIP5X
Range0.1 ~ 25 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 2 W
Weight90 ~ 92 g
Long Distance Series Product Model
TFA170-L
TFA170-L
Learn More Add to Comparison
Dimensions (L*W*H)31.0 mm × 30.2 mm × 19.2 mm
InterfaceRS-232
Protection Levelwithout enclosure
Range0.1 ~ 170 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 1 W
Weight~ 10 g
TF03
TF03
Learn More Add to Comparison
Dimensions (L*W*H)44 mm × 43 mm × 32 mm
InterfaceUART, CAN, RS-232, RS-485
Protection LevelIP67
Range0.1 ~ 180 m
Frame Rate1 ~ 9800 Hz
Power Consumption≤ 1 W
Weight86 ± 3 g
TFA300 Series
TFA300 Series
Learn More Add to Comparison
Dimensions (L*W*H)49.4 mm × 37.0 mm × 28.6 mm
InterfaceUART, CAN
Protection LevelIP67
Range0.1 ~ 290 m
Frame Rate1 ~ 10,000 Hz
Power Consumption≤ 0.45 W
Weight10.5 g
TF350
TF350
Learn More Add to Comparison
Dimensions (L*W*H)78 mm × 67 mm × 40 mm
InterfaceUART, CAN, RS-232, RS-485
Protection LevelIP67
Range0.2 ~ 350 m
Frame Rate1 ~ 1000 Hz
Power Consumption≤ 1 W
Weight224 ± 3 g
Kilometer-level
TFA1200-L
TFA1200-L
Learn More Add to Comparison
Dimensions (L*W*H)25 mm × 25 × 13 mm
InterfaceUART
Protection Levelwithout enclosure
Range3 ~ 1200 m
Frame Rate3 Hz
Power Consumption< 1.1 W
Weight11 g
TFA1500-L
TFA1500-L
Learn More Add to Comparison
Dimensions (L*W*H)≤ 25 mm × 26 mm × 13 mm
InterfaceUART
Protection Levelwithout enclosure
Range0.5 ~ 1500 m
Frame Rate60 ~ 800Hz (adaptive)
Power Consumption≤ 1.8W
Weight11 g
2D Series..

NOVA20
NOVA20 LiDAR
NOVA20 LiDAR
Learn More Add to Comparison
Dimensions (L*W*H)≤25 * 21 * 14mm
InterfaceUART
Protection Levelwithout enclosure
Range1m@10 %Reflectivity, 100Klux
Frame Rate10Hz
Power Consumption< 1W
Weight< 5g
VLS Series
VLS-H5
VLS-H5
Learn More Add to Comparison
Dimensions (L*W*H)52.0 mm × 75.0 mm × 53.1 mm
InterfaceUART
Protection LevelIPX8
Range5 m
Frame Rate6 Hz
Power Consumption
Weight125g
TR Series
TR Serise
TR Serise
Learn More Add to Comparison
Dimensions (L*W*H)60 mm × 60 mm × 80 mm
Interface
Protection LevelIP65
Range40 m
Frame Rate10 ~ 30 Hz
Power Consumption
Weight
3D Series..

Long Distance Series Product Model
SR18
SR18
Learn More Add to Comparison
Dimensions (L*W*H)Ø71.8 mm × 64 mm
InterfaceRS-485
Protection LevelIP66
Range30 m @10%
Frame Rate5 Hz
Power Consumption≤5 W
Weight190g
LR10 series
LR10 series
Learn More Add to Comparison
Dimensions (L*W*H)92 mm × 47 mm × 51 mm
InterfaceEthernet, GMSL, I/O
Protection LevelIP67
Range0.05-18m
Frame Rate10fps
Power Consumption
Weight460g
AD2-S-X3
AD2-S-X3
Learn More Add to Comparison
Dimensions (L*W*H)49 mm × 160 mm × 144 mm
Interface1000Base-T1 Automotive Ethernet
Protection LevelIP67 & IP6K9K
Range300 m @ 10%
Frame Rate10 Hz
Power Consumption≤ 15 W
Weight1.2 kg
Horn-X2 Pro
Horn-X2 Pro
Learn More Add to Comparison
Dimensions (L*W*H)192.6 mm × 157 mm × 126 mm
Interface1000Base-T
Protection LevelIP67
Range300 m @ 10%
Frame Rate1 ~ 20 FPS
Power Consumption≤ 35 W
Weight≤ 3.8 kg
Horn-RT
Horn-RT
Learn More Add to Comparison
Dimensions (L*W*H)183 mm × 157 mm × 120 mm
Interface1000Base-T
Protection LevelIP67
Range300 m @ 10%
Frame Rate1 ~ 20 FPS
Power Consumption≤ 35 W
Weight≤ 3.3 kg
Applications
Autonomous Mobility
ADAS Unmanned Mining Trucks Smart Logistics - Last-Mile Unmanned Delivery Autonomous Driving Truck Operation
UAV
Terrain Following Position Hold
Level Detection
Level Detection Volume Detection Liquid level measurement Space & People Flow Detection
Robot
Pallet Transport Robot Obstacle Avoidance Crane Positioning / Obstacle Avoidance Robot Fall Prevention & Obstacle Avoidance AGV/AMR Forward Obstacle Avoidance Robotic Lawn Mowers
Smart Transportation
Vehicle Door Obstacle Avoidance Smart Parking Automotive Electric Tailgate Highway Key Area Monitoring V2X / Holographic Intersection / Traffic Light Control Meli train collision avoidance system Smart Civil Aviation
IoT
Auxiliary Focus Smart Trigger Security Warning Rotary door anti-clamping Blind cane
